Series SN
Single-phase automatic voltage stabiliser
Series SN
Single-phase automatic voltage stabiliser
Single-phase voltage stabiliser for fast and automatic correction of the output voltage in the event of mains voltage variations and load consumption variations.
Features
- Continuous regulation by serial booster between input/output and motorised variable autotransformer.
- High resolution digital controller.
- Display for output voltage visualisation.
- Magneto-thermal ON/OFF switch on the front panel.
- Terminal connection inside to protect against dangerous direct contacts.
Specifications
| Power (kVAr) | 1 ÷ 60 kVA |
| Input Voltage (V) | 230 V |
| Input Margin | ± 15% |
| Output Voltage (V) | 230 V |
| Output Accuracy | ± 1% |
| Response time | ≈ 20 V/s |
| Frequency | 50/60 Hz |
| Ambient Temperature | 30 ºC |
| PI | IP23 |
| Service | Continuo |
| Harmonic Distortion | Nula |
| Efficiency | >95% |
| Regulations |
IEC/UNE-EN 61439-1 IEC/UNE-EN 61558-1 IEC/UNE-EN 60076-11 |
Quality Seals
Uses
- Data centres and processing.
- Telecommunications and broadcasting
- Hospitals and medical centres.
- Offices, hotels and shops.
- Industrial machinery, motors, robots, lasers.
- Sensitive electrical or electronic equipment
Product Versions
| References | POWER (kVA) | INTENSITY (A) | ||
|---|---|---|---|---|
| Entrance | Exit | |||
| SN01 | 1 | 4.348 | 4.348 | Show details |
| SN02 | 2 | 8.696 | 8.696 | Show details |
| SN03 | 3 | 13.043 | 13.043 | Show details |
| SN05 | 5 | 21.739 | 21.739 | Show details |
| SN07 | 7.5 | 32.609 | 32.609 | Show details |
| SN10 | 10 | 43.478 | 43.478 | Show details |
| SN15 | 15 | 65.217 | 65.217 | Show details |
| SN20 | 20 | 86.957 | 86.957 | Show details |
| SN25 | 25 | 108.696 | 108.696 | Show details |
| SN30 | 30 | 130.435 | 130.435 | Show details |
| SN40 | 40 | 173.913 | 173.913 | Show details |
| SN50 | 50 | 217.391 | 217.391 | Show details |
| SN60 | 60 | 260.87 | 260.87 | Show details |
Show more +
* TORYTRANS reserves the right to modify the information in any time and
without prior notice. Design, dimensions or weight of the product could be
different.
